EF81 Datasheet

Product Profile

• Complete UMTS feature set in a 15.9 mm slim clamshell design
• Superb quality of detail demonstrated by real magnesium housing, brushed stainless steel front and keypad, aluminum rear cover and applications combined with an extremely flat metal keypad and hardened mineral glass external display
• Can be operated conveniently when closed due to a large second display (120 x 160 pixels, QQVGA) and four keys on the upper case enabling the use of main applications without opening the device

Features

• Exciting visual experience provided by full video capability and a large 2.2 inch display with high-color depth
• Extremely flat stainless steel keypad with electroluminescent foil illumination
• Video telephony
• 2.0 megapixel camera for picture and video taking
• High-resolution displays (QVGA/QQVGA) with brilliant colors (TFT, 262,144 colors)
• Dedicated keys on upper case for using main functions (camera, MP3) and call handling in closed mode
• Media player for music and video; MP3-AAC++, MPEG4, RealVideo 8/9, h.263, 3GPP
• Video download and streaming
• 64-chord polyphonic ringtones; MP3-AAC++, real audio 8 enhanced
• Micro SD card slot
• MMS, e-mail client, IMPS
• Speaker dependent (SD) voice dialing
• Bluetooth® and USB support
• State-of-the-art Headset Bluetooth® Comfort as accessory

Technical Data

• Dimensions: 94 x 51x 15.9 mm
• Weight: 110 g
• Standby time: GSM: up to 300h; UMTS: up to 250h
• Talktime: GSM: Approx 4.5 h; UMTS: approx 3.5 h
• Battery: Li-Ion 950 mAh
• Antenna: Integrated
• Main-display: QVGA 240 x 320 pixels, 2.2 inches, TFT, 262,144 colors
• Sub-display: QQVGA 120 x 160 pixels, 1.3 inches, TFT, 262,144 colors
• Camera: 2.0 megapixel camera, 5x digital zoom rotating hinge camera
• Connectivity: Bluetooth®, USB
• Storage: Internal user memory: 64 MB, Micro SD card slot

System/Standards

• GSM: Tri-band 900/1800/1900
• UMTS: W-CDMA 2100
• GPRS Multislot cIass 10
• SIM Functionality/Security Controls
• SIM Application Toolkit (Rel. 99)
• SIM lock, various levels
• PIN 1 & 2 control

Services

• SMS, MMS rel. 4, MMS postcard service, IMPS, e-mail
• Browser: OMA browsing 2.0, XHTML-MP, wCSS (98%), wTCP/IP, WML 1.3, dual stack (whttp, WSP 1.x); OMA download OTA; SSL 3.0/TLS 1.0
• Java: MIDP 2.0; CLDC 1.1, JTWI 1.1
